FC/Hausmarke Schott Connector Ø5Mm 'Qsvp 5 Msv' ticari katalogda listelenen bir üründür (Q MSV Series Plug Connectors) ve üreticisi FC/Hausmarke olarak kaydedilmiştir. Üretici referansı 200010399 kodudur. Dokümantasyon eşleştirme, yedek parça tespiti veya satın alma talebi hazırlarken bu kodu kullanın.
FC/Hausmarke Schott Connector Ø5Mm 'Qsvp 5 Msv'
FC/Hausmarke Schott Connector Ø5Mm 'Qsvp 5 Msv'
Producer: FC/Hausmarke
Ürün Kodu: Schott Connector Ø5Mm 'Qsvp 5 Msv'
FC/Hausmarke Schott Connector Ø5Mm 'Qsvp 5 Msv' product information
FC/Hausmarke Schott Connector Ø5Mm 'Qsvp 5 Msv' is catalogued under Accessories Program / Quick Connector / Q MSV Series Plug Connectors. The manufacturer reference for this item is 200010399. Use this exact designation when comparing documentation, identifying a replacement or preparing a purchasing enquiry.
Available technical information
Features:- Plug-In System With Elastic Collet Made Of Stainless Steel
- Hose Assembly With One Hand
- For Hoses Of Different Materials (Pu, Pa)
- Small Size And Low Weight
- Silicone-Free O-Rings (Depending On Version)
- O-Ring In Sealing Groove - For Rough Surfaces (Depending On Version)
- Modular, Flexible Structure
- Hexagon Socket For Easy Installation (Depending On Version)
Operating Temperature:
-20°C To +80°C (For Screw Connections With O-Rings Made Of Nbr)
Operating Pressure: Up To 16Bar - Depending On The Pressure Range Of The Hose Used
Vacuum: Max. 98%
Materials:
Brass (Ms58) Nickel-Plated Housing
Seals Made Of Nbr Silicone-Free (Depending On Version)
Collet Made Of Stainless Steel 1.4401
Pressure Ring/Release Ring Made Of Nickel-Plated Brass
Thread Types (Note Item Description):
Cylindrical Thread Din En Iso 228, Cylindrical With O-Ring Seal
Conical Thread Din En 10226 (Din 2999)
Metric Thread Din Iso 261
Medium: Oiled And Unoiled Compressed Air - Media That Are Compatible With The Materials Of The Components
Hoses: For Cables According To Iso 14743, Recommended Materials: Pu, Pa
Tolerances For Outside Ø 4 To 8: ±0.1
Tolerances For Outside Ø 10 To 14: ±0.15 (Pu), 10 To 14: ±0.1 (Pa)
Technical and compatibility checks
Before ordering, verify the complete product code against the manufacturer documentation and the installed component. For products in this group, relevant checks commonly include dimensions, material, operating ratings, connections, mounting arrangement and compatibility with the intended application. Structured specification fields available on this page should also be compared with the required configuration. A shared family description may cover several variants, so the exact suffixes and ratings remain important.
- Producer: FC/Hausmarke
- Manufacturer reference: 200010399
- Catalogue category: Accessories Program / Quick Connector / Q MSV Series Plug Connectors
Availability and quotation request
Use the quotation form with the required quantity, delivery destination and application details. If the item is intended as a replacement, include the full nameplate reference or supporting technical document so the requested variant can be checked before a commercial response is prepared.
Item Number: 200010399
Designation: Qsvp 5 Msv
Manufacturer: Fc/House Brand
Plug Connection Version: Bulkhead Connector Screw-On And Plug-In Connector
Material/Material: Nickel-Plated Brass
Hose Ø1 Outside: 5 Mm
Hose Ø2 Outside: 5 Mm
Weight: 0.0130 Kg
Country Of Origin: Italy
Customs Tariff Number: 74122000
Sales Unit: Pcs.
Request Item: No
Ürün soruları
Sıkça sorulan sorular
FC/Hausmarke, bu kayıt için üretici olarak belirtilmiştir. Aynı üreticiye ait diğer ürünler kataloğun FC/Hausmarke marka sayfasında gruplanmıştır.
Available technical informationFeatures: - Plug-In System With Elastic Collet Made Of Stainless Steel - Hose Assembly With One Hand - For Hoses Of Different Materials (Pu, Pa) - Small Size And Low Weight - Silicone-Free O-Rings (Depending On Version) - O-Ring In Sealing Groove - For Rough Surfaces (Depending On Version) - Modular, Flexible Structure - Hexagon Socket For Easy Installation (Depending On Version) Ope... Sipariş öncesi tam kodu güncel üretici dokümantasyonuyla doğrulayın; aile tanımı birden fazla varyantı kapsayabilir.
Bu kayıtta üretici veri sayfası ekli değildir. Teklif formundan güncel doküman talep edin; üretici referansı olarak 200010399 ve üretici FC/Hausmarke bilgisini belirtin.
Bu katalog liste fiyatı yayınlamaz. Bu ürün sayfasındaki teklif formunu miktar, teslimat adresi ve uygulama bilgileriyle kullanın. Sekabet: Paxild Online, istenen varyant kontrol edildikten sonra ticari yanıt hazırlar. Yedek parça için etiket/referans veya teknik doküman ekleyin. İletişim sayfasını da kullanabilirsiniz.
